ActiveIO-LinkEtherNet/IP IO-Link mastersOrder code: 78330001
ELIP-8IOL-L001ELIP-8IOL-L001 EtherNet/IP IO-Link master
ELIP-8IOL-L001 is an 8-port IO-Link master for EtherNet/IP networks. It has Class A IO-Link ports, two D-coded M12 Ethernet ports, an integrated Ethernet switch, 100BASE-TX support and IP67 protection.
EtherNet/IPIO-LinkEtherNet/IP IO-Link mastersIP67M12







Features
EtherNet/IP
Integrated Ethernet switch
Supports 100BASE-TX
Two D-coded M12 Ethernet ports
8-port IO-Link master
IO-Link specification V1.1
IO-Link master ports: Class A
IO-Link master ports: M12 A-coded
Metal connectors with a high-strength plastic housing
Shock and vibration resistant
Electronics potted in resin
IP67 protection
Specifications
- Supply voltage
- 24VDC ± 10%
- Operating current
- < 200mA
- Supply current
- Recommended >8A
IO–Link port parameters
- Number of ports
- 8 (C1...C8)
- Connectivity inputs
- M12, A–coded, Female
- Common IO pins
- Not supported. The second hole needs to be left empty.
- Port supply current
- The maximum is 2A, which is the current provided by the first hole to the device. The total of C1...C4 does not exceed 4A The total of C5...C8 does not exceed 4A
IO–Link parameters
- SIO model
- Not Supported,The 4th hole cannot be used as a normal I/O.
- IO–Link Pin definition
- Pin 4 in IOL mode
- IO–Link Port type
- Class A, The second hole needs to be left empty.
- IO–Link specification
- V1.1
- Frame type
- Supports all specified frame types
- Support Device
- Maximum 32Bytes Input / 32Bytes Output
- Transmission rate
- 4.8kbps(COM1) / 38.4kbps(COM2) / 230.4kbps(COM3)
Ethernet/IP
- Number of communication interface
- 2
- Transmission standard
- 100Base–TX
- Auto–negotiation
- Supported
- Auto–MDI/MDIX
- Supported
- Maximum transmission rate
- 100Mbit/s
- Connector
- M12, D–coded, Female
- Default IP address segment
- 192.168.0.*
- IP address setting function
- support DHCP
- Default subnet mask
- 255.255.255.0
- Communication data format
- Binary
- Operating temperature
- –20–55°C
Documents
Configuration fileVersion V5.6
ELIP-8IOL-L001 Device description file
For models: ELIP-8IOL-L001Order codes: 78330001Updated: 2026-08-20Size: 4.9 KB
CAD drawing (DWG)
ELIP-8IOL-L001 CAD drawing (DWG)
For models: ELIP-8IOL-L001Order codes: 78330001Updated: 2026-08-20Size: 89.0 KB
3D model (STP)
ELIP-8IOL-L001 3D model (STP)
For models: ELIP-8IOL-L001Order codes: 78330001Updated: 2026-08-20Size: 5.7 MB
EPLAN
ELIP-8IOL-L001 EPLAN
For models: ELIP-8IOL-L001Order codes: 78330001Updated: 2026-08-20Size: 27.1 MB
Datasheet
ELIP-8IOL-L001 datasheet
For models: ELIP-8IOL-L001Order codes: 78330001Updated: 2026-10-07Size: 0.51 MiB
Accessories
Accessories and connectivity
Published accessory products; open any of them for full details.
Compare models in this series
All EtherNet/IP IO-Link masters (2)| Model | Operating voltage | Current consumption | Supply current | Channels | View details | |
|---|---|---|---|---|---|---|
![]() | ELIP-8IOL-L001This model | 24VDC ± 10% | < 200mA | Recommended >8A | 8 (C1...C8) | |
![]() | ELIP-8IOL-L04BSame family · differs only in supply current | 24VDC ± 10% | < 200mA | — | 8 (C1...C8) | → |
